Okuma MCV-AII Double Column Machining Center 2003

Make: Okuma

Model: MCV-AII

CNC Control: OSP-E100M

Year: 2003

Ref: 1484

Specifications

 X - 3000 mm (118.11")

 Y - 1600 mm (62.99")

 Z - 450 mm (17.72")

W - 1000 mm (38.37")

Rapid Traverse X-Y/Z : 20/10 m/min. (787.4"/393.7" IPM)

Spindle Speed : 6000 rpm

Spindle Power : 30/25 Hp

Tool shank : MAS BT50

ATC : 50 Tool

Table size : 1500 x 3000 mm (59.05" x 118.11")

Max. load : 8000 Kg (17600 Lbs)

Table to Spindle nose : 0 ~ 1360 mm (0 ~ 53.54")

Distance Between Columns : 2050 mm (80.71")
